Overview:
Got big jobs but tired of small machine headaches? Meet the HAWK Merlin WD 20" - the contractor's answer to large-area surface prep. This isn't just a wider version of Hawk's 17" beast - it's a production-maximizing monster that lets you demolish concrete resurfacing and stone polishing jobs in record time. Finally, a machine that matches your ambition.
Why It Stands Out:
Here's the truth about large-area prep work: standard rotary machines are killing your productivity and your back. The Merlin WD 20" changes everything with its floating head design that practically drives itself. We're talking 1.5 HP of raw power spread across a 20" path, with triple-planetary gears that laugh at the work that burns up lesser machines. And yeah, one person can disassemble it in 60 seconds flat.
What Customers Love:
Contractors running the 20" Merlin are reporting game-changing results. Jobs that used to take days are wrapping up ahead of schedule. The forward-motion control means operators aren't exhausted halfway through the shift. Plus, the modular design means you're not calling for backup just to get it on and off the truck. When time is money, this machine is basically a printing press.
Three Versatile Models:
Perfect For:
Stop letting small machines eat up your profits on big jobs. The HAWK Merlin WD 20" is built for contractors who are done making excuses and ready to dominate large-scale surface prep. Whether you're resurfacing vast concrete areas or tackling premium stone jobs, this beast lets you cover more ground without sacrificing an ounce of power. Available in TE (black powder-coat) or TECP (chrome accent) finish, with an optional DX package for maximum versatility. Ready to stop working harder and start working smarter? This is your machine.
| Model | Merlin 20 TE | Merlin 20 TECP | Merlin 20 TEDX |
| Part# | F70-20-01 | F70-20-01-CP | F70-20-01DX |
| Motor / Cover | Black Motor & Powder Coated Frame | Chrome Motor & Powder Coated Frame | Chrome Motor & Brush Cover, Powder Coated Frame |
| Machine Size | 20″ | 20″ | 20″ |
| Pad Speed | 165 RPM | 165 RPM | 165 RPM |
| Amp Draw | 8.5 | 8.5 | 8.5 |
| Motor | 1.5 HP, 180 frame, TEFC dual capacitor AC | 1.5 HP, 180 frame, TEFC dual capacitor AC | 1.5 HP, 180 frame, TEFC dual capacitor AC |
| Power | 115-230V, 60 (50 Hz optional) | 115-230V, 60 (50 Hz optional) | 115-230V, 60 (50 Hz optional) |
| Power Cord | 50 ft, (12-3) 2-piece industrial w/ twist lock | 50 ft, (12-3) 2-piece industrial w/ twist lock | 50 ft, (12-3) 2-piece industrial w/ twist lock |
| Drive Gears | Triple-planetary XHD 11:1 helical-cut industrial | Triple-planetary XHD 11:1 helical-cut industrial | Triple-planetary XHD 11:1 helical-cut industrial |
| Sound Level | 66 dB – Meets GS 42 standard | 66 dB – Meets GS 42 standard | 66 dB – Meets GS 42 standard |
| Weight | 231 lbs. | 231 lbs. | 260 lbs |
| Dimensions | 25 × 33 × 55 in | 25 × 33 × 55 in | 25 × 33 × 55 in |
