Airrex HSC-60R 60,000 BTU Portable Spot Cooler

The Airrex HSC-60R is a heavy-duty portable air conditioner built for industrial sites, repair shops, warehouses, and outdoor venues where standard cooling units simply can’t keep up. At 60,000 BTU (5 tons of cooling), the HSC-60R is engineered to cool spaces up to about 2,500- 3,500 sq ft, depending on ceiling height, insulation, and heat load, making it one of the most powerful single-unit portable spot coolers available.

Unlike residential portable ACs that recirculate room air, this self-contained spot cooler exhausts heat through a dedicated exhaust duct, making it suitable for open or semi-open industrial environments. It runs in cooling, fan, and dehumidifier modes, with a temperature range of 64-86°F in cooling mode, and operates reliably in ambient temperatures from 65 to 115°F.

The HSC-60R uses R-454B refrigerant, which carries a Global Warming Potential (GWP) of 466 - roughly 78% lower thanR-410A’ss GWP of 2,088. That puts it in compliance with California Air Resources Board (CARB) standards and aligned with EPA AIM Act requirements, so you’re covered whether you’re operating in California or anywhere else in the country.

Tired of dealing with air conditioners that can’t handle the heat or don’t offer enough cooling?

Are you:

• Struggling with air conditioners that lack power for large spaces?
• Frustrated by constant adjustments or noise during operation?
• Looking for a reliable portable cooling solution that’s easy to move and maintain?

The Airrex HSC-60R offers seamless cooling and flexibility for any setting, keeping you comfortable no matter the temperature.

Why Choose the Airrex HSC-60R?

The HSC-60R earns its place in demanding environments by combining industrial-grade cooling capacity with the mobility and self-contained design that fixed HVAC systems can’t offer. See the feature differentiators and use-case details below.

Available Variants

• 220V 1ph 60Hz - Model, HSC-60R 220/1
• 220V 3ph 60Hz - Model, HSC-60R 220/3
• 480V 3ph 60Hz - Model, HSC-60R 480/3

Select the 220V 1-phase model for standard commercial single-phase service. Choose the 220V or 480V 3-phase models for industrial facilities with three-phase electrical infrastructure and confirm your panel’s breaker amperage before ordering. All three variants use a NEMA 6-30P plug; 3-phase models require a licensed electrician for hookup.

Why the Airrex HSC-60R Stands Out

• Impressive Cooling Power: 60,000 BTU handles large, high-heat environments that would overwhelm a standard portable AC unit.
• Versatile Operation Modes: Switch between cooling, fan, and dehumidifier modes depending on what the space needs.
• Automatic Fan Speed: The fan adjusts automatically based on ambient conditions, so you don’t have to babysit the controls.
• Quiet and Efficient: Designed for non-disruptive operation - useful in occupied warehouses, event tents, or server rooms where noise matters. R-454B refrigerant delivers efficient cooling with a GWP of 466, meeting CARB compliance and EPA AIM Act standards.
• Auto-Restart After Power Outage: Automatically resumes prior settings when power is restored, which is critical for unattended overnight operation in industrial facilities.
• High-Efficiency Condensate Management: The built-in condensate pump automatically removes collected moisture, and the auto shut-off prevents overflow without requiring a floor drain.

Perfect for

This industrial AC unit is purpose-built for situations where permanent HVAC isn’t an option or isn’t enough. Here’s where it earns its keep:

• Warehouses and Distribution Centers: Targeted cooling at loading docks or packing stations where central HVAC doesn’t reach.
• Repair Shops and Garages: Handles the heat load from welding equipment, lifts, and vehicle exhaust in spaces that can’t be fully sealed.
• Outdoor Events and Tents: Spot-cools VIP areas, catering stations, or production tents during summer events.
• Server Rooms and Temporary Data Centers: Delivers supplemental cooling during HVAC maintenance windows or emergency outages.
• Construction Sites: Cools temporary site offices or enclosed work areas where permanent HVAC isn’t installed yet.

How to Size a Portable Air Conditioner for Your Space

Choosing the right BTU rating is the most important decision when buying a portable air conditioner. Here’s the practical breakdown for industrial and commercial spaces:

Start with square footage. A general rule of thumb for commercial and industrial cooling is 20-25 BTU per square foot at a standard 8-foot ceiling height. At 60,000 BTU, the HSC-60R covers roughly 2,400 - 3,000 sq ft under that baseline.

Adjust for ceiling height. Taller ceilings mean more cubic footage to cool. A warehouse with 20-foot ceilings holds 2.5x the air volume of a standard room, which means you need proportionally more sensible cooling capacity.

For high-bay spaces, calculate by cubic footage rather than square footage. Multiply your floor area by ceiling height, then target about 1 BTU per 1.5-2 cubic feet.

Factor in heat load. Heat-generating equipment such as welding stations, server racks, commercial ovens, and vehicle engines adds significant BTU load on top of the ambient temperature. A server room with 10 kW of active equipment adds roughly 34,000 BTU/hr of heat load, before you even account for room size.

Ambient temperature matters. The HSC-60R is rated to operate in ambient temperatures up to 115°F, which covers most outdoor summer conditions and hot industrial environments. Units rated only to 95°F will struggle or shut down in those same conditions.

The bottom line on 5-ton cooling: A 60,000 BTU portable spot cooler is not a residential unit. It’s the right call for large open spaces, high heat loads, extreme ambient temperatures, or any combination of the three. If your space is under 1,500 sq ft with a normal heat load, a smaller 24,000-36,000 BTU unit will serve you better and cost less to run. But if you’re cooling a 3,000 sq ft warehouse floor in July, the HSC-60R is built for exactly that.

What Customers Love

• “Powerful enough for large spaces and works without constant adjustments.”
• “The auto-restart feature is a lifesaver in power outages.”
• “Easy to move around with the locking swivel casters - no hassle!”

Equip yourself with the Airrex HSC-60R for efficient, portable cooling that works as hard as you do.

Key Features and Benefits of the Airrex HSC-60R 60,000 BTU Portable Spot Cooler

• Cooling Power: 60,000 BTU (5 tons) to cool large industrial or commercial spaces up to approximately 2,500- 3,500 sq ft.
• 3 Operating Modes: Cooling, fan, and dehumidification for versatile use across different environments.
• Automatic Fan Speed Control: Adjusts based on ambient conditions for consistent performance without manual intervention.
• Exhaust Duct Compatible: Designed to connect to flexible exhaust ducting for heat removal - required for proper spot cooler operation in enclosed or semi-enclosed spaces.
• Digital Control Panel: Intuitive digital display for precise temperature setting between 64- 86°F.
• New Eco-Friendly Refrigerant: R-454B with a GWP of 466 - CARB-compliant and EPA AIM Act aligned, roughly 78% lower GWP than R-410A.
• Removable, washable filters: Easy to pull, rinse, and reinstall for long-term performance without filter replacement costs.
• High-Efficiency Condensate Pump: Automatic condensate removal with auto shut-off - no floor drain required.
• Quiet Operation: Suitable for occupied spaces where noise disruption is a concern.
• Locking Swivel Casters: Roll it where you need it, lock it in place. Easy to move and secure wherever you need it.
• Programmable Timer: Set operation for up to 24 hours for unattended or overnight use.

Warranty

Standard warranty on all of TEMP-AIR’s units manufactured by Airrex is one year, covering parts and labor for manufacturer defects. The compressor carries a three-year warranty, reflecting AiAirrex’sonfidence in the hermetically sealed scroll compressor used across the HSC-60R series.

In the unlikely event you have any problems, please Contact Us. If the problem is the result of a production fault or failure, repairs will be undertaken free of charge during the warranty period, subject to the following conditions,

1. If the problem is caused by customer error, misuse, abuse, or damage, all repairs will be charged.
2. This warranty applies to your country.
3. Proof and date of purchase must be supplied.
4. Keep all original packaging to facilitate return.

Returns

Confidence Comes Standard, 30-Day Free Returns, Zero Risk - See Full Return Policy Here

Frequently Asked Questions

Here are the most common questions buyers ask before purchasing the Airrex HSC-60R.

What size space can the HSC-60R cool?

At 60,000 BTU (5 tons), the HSC-60R is rated for approximately 2,500- 3,500 sq ft at standard ceiling heights. That range narrows in high-ceiling industrial spaces or rooms with significant heat-generating equipment. Use the sizing guidance above to calculate your specific heat load before ordering.

Does the HSC-60R require an exhaust duct?

Yes. Like all self-contained spot coolers, the HSC-60R must exhaust heat through a flexible duct to an adjacent space or outside. Without proper exhaust, the unit recirculates hot air and loses cooling effectiveness. Confirm the duct diameter in the spec sheet, and ensure your installation allows proper heat rejection.

What electrical outlet does the HSC-60R use?

All three variants use a NEMA 6-30P plug. The 220V 1-phase model works with standard commercial single-phase service. The 220V and 480V 3-phase models require a three-phase electrical supply and should be connected by a licensed electrician - confirm your panel’s breaker amperage before ordering.

Is R-454B refrigerant safe and legal in California?

Yes. R-454B has a GWP of 466, which is approximately 78% lower than R-410A’s GWP of 2,088. It meets California Air Resources Board (CARB) requirements and is aligned with EPA AIM Act regulations. This makes the HSC-60R one of the few portable spot coolers at this capacity that’s fully compliant for California operation.

How is condensate water handled?

The HSC-60R includes a built-in condensate pump that automatically removes collected moisture during operation. An auto shut-off prevents overflow if the system reaches capacity. No floor drain is required, which makes installation straightforward in spaces without existing drainage infrastructure.

Can the unit restart automatically after a power outage?

Yes. The auto-restart feature resumes prior settings when power is restored. This is particularly useful for overnight or unattended operation in industrial facilities where no one is on-site to manually restart the unit after a power interruption.

Airrex HSC-60R 60,000 BTU Portable Spot Cooler Air Conditioner - 5 Ton Specs

All three variants share identical physical dimensions and cooling output. The only differences are voltage, phase, and power cord length - choose based on your facility’s electrical supply.

Airrex HSC-60R 60,000 BTU Portable Spot Cooler Air Conditioner Resources

Airrex HSC-60R 60,000 BTU Portable Spot Cooler Air Conditioner Owner's Manual

Airrex HSC-60R 60,000 BTU Portable Spot Cooler Air Conditioner Diagram

Airrex HSC-60R 220V 1PH Specs

Airrex HSC-60R 220V 3PH Specs

Airrex HSC-60R 480V 3PH Specs
